S770 Barcode Scanner

Model: S770 or S770-W
Description: Bluetooth Scanner, 2D barcode scanner
Key parameter: 300 times/sec scanning speed
USB, Bluetooth, 2.4G

Send Inquiry

Description

Features:

1. 2D scanner, Innovative chic design

Exquisite aesthetic and stylish appearance, comfortable grip, soft lighting and accurate reading system, help reduce the operator’s daily scanning fatigue, and improve work efficienc.

2. Wireless barcode scanner. Multiple connections

Dual wireless (2.4G + Bluetooth) is a perfect combination of high performance long distance connection technology making scanning easily and freely.

Support USB communication, plug and play.

3. S770 Barcode Scanner, High performance scanning

Professional 2D scanning engine with accurate and fast scanning performance, not only can accurately read the barcodes on paper and commodities, but also has superior reading ability for barcodes displayed on various screens to meet the high-end scanning performance requirements.

4. Inventory scanner, Diverse scanning feedback

With a highlight buzzer, LED indicator and motor vibration, scanning actions can clearly indicated even in noisy environments.

Specification

Basic Characteristics
Dimension	16.568.4 cm
Color	Wine red
Weight	382g (without cable)
Light Source	Aiming Pattern: Square 617 nm Red LED
Illumination	6500K LEDs
Image Sensor	640*480 pixels
Minimum print contract	25%PCS
Scan Angle	Pitch: ±65°
	Roll: 0-360°
	Skew: ±60°
Indicators	Beeper, LED
Scan Pattern	Manually trigger (standard), Presentation mode (blink)
Motion tolerance	63.5cm/s
Decode Range (Typical)
5mil (code39)	1.1~6.5inch (2.8~16.5cm)
13mil (UPC-A)	0.5~9.7inch (1.3~24.6cm)
20mil (QR code)	0.5~15.2inch (1.3~38.6cm)
6.8mil (PDF417)	0.9~7inch (2.3~17.8cm)
10mil (Datamatrix)	1.1~7.5inch (2.8~19.1cm)
Support Host interface	RS232, USB, USB-COM
Environmental
Operating Temperature	-20°C to 50°C
Storage Temperature	-40°C to 80°C
Humidity	5% to 95%, non-condensing
Drop/Tumbl	Desinged to withstand 50 drops on concrete from 1.2m
Light levels	100000Lux Max.
Decode Capabilities
1D	EAN-8, EAN-13, Codabar, CODE 39, CODE 93, CODE 128, China Post, GS1-128, UPC-A, UPC-E, UCC/EAN 128, ISBN/ISSN, ISBT, Interleaved 2 of 5, Standard 2 of 5, Matrix 2 of 5, Industrial 2 of 5, MSI, RS, ITF14, Telepen, etc.
2D	QR Code, Micro QR Code, Data Matrix, PDF 417, Micro PDF417, Maxicode, Aztec, Hanxin, etc.
Wireless features (optional)
Bluetooth Version	2.1+4.1 (support HID, SPP, BLE mode)
Communication Distance	More than 10m
2.4GHz (visible distance)	More than 150m
Electrical Parameter (optional)
Current	3.3V DC±5%, 280mA
Battery	1800mAh
Charging times	Less than 3 hours
Standby times	More than 30 days
Operation times	More than 70 hours, 1 scan/5second
Electrostatic Discharge (ESD)	+/- 15kV Air, +/- 18kV Direct, +/- 8kV Indirect
